Payments12 min readUpdated October 14, 2026

How to Integrate a Payment Gateway: Types, PCI Scope and Multiple Gateways

Payment gateway integration step by step: hosted page, embedded fields or API, the PCI SAQ each puts you in, webhooks, 3DS, tests and multiple gateways.

Nick Bonnassies, CMO at Tagada · checked against 17 sources

Article summary

TL;DR

To integrate a payment gateway, open a merchant account, pick how card data is collected (hosted page, embedded fields, direct API or a store plugin), build the server call with idempotency keys, confirm payments through signed webhooks, handle 3D Secure, then test declines and duplicates in the sandbox before switching to live keys.

The integration type decides your PCI workload: a hosted page or a provider iframe can qualify for SAQ A, your own form posting to the gateway is SAQ A-EP, and card numbers on your servers mean far more controls.
Since March 31, 2025, an embedded payment form only qualifies for SAQ A if the page is protected against script attacks. A full redirect is not concerned.
Never fulfill an order from the success page. Confirm it from a verified webhook, and make every handler safe to run twice.
In the EEA, a customer-initiated card payment needs Strong Customer Authentication unless an exemption applies: build the 3D Secure step in from day one.
Several gateways means one layer for routing, failover and reporting. Saved cards are the hard part: a token from one processor can't be charged at another.

Want to go further? Ask

On this page

Integrating a payment gateway takes more than adding a pay button. You choose how card details are collected, and that choice sets your PCI DSS workload. Then come the server calls, the webhooks that confirm each payment, 3D Secure and the tests. This guide covers the four integration types, what PCI asks of each since the 2025 change to SAQ A, the steps from sandbox to live, and what changes when you connect several gateways.

What payment gateway integration covers

A payment gateway takes the payment details from your checkout and passes them to the processor and the card networks for approval. The gateway and the processor are often the same company, but their roles differ: see payment gateway vs payment processor.

Whatever the provider, an integration has the same five parts:

Part	What it does	Who builds it
Merchant account	The contract that lets you accept cards and get paid out	The provider, after underwriting
Payment form	Collects card or wallet details in the browser or app	The provider, you, or both, depending on the integration type
Server call	Creates the payment with your secret key and the amount you trust	You
Webhooks	Tell your server what happened afterwards: paid, failed, refunded, disputed	The provider sends them, you handle them
Reconciliation	Matches payments, fees and payouts with your orders	You, or your accounting tool

The payment form is where the big decision sits, because it decides whether card numbers ever touch your systems.

The four ways to integrate a payment gateway

Every major gateway offers the same families of integration, under different names.

Integration type	How it works	Examples	Control over the page	Usual PCI questionnaire
Hosted payment page (redirect)	The customer leaves your site to pay on the provider's page, then comes back	Stripe Checkout hosted page, Authorize.net Accept Hosted, PayPal	Low: logo and colors	SAQ A
Embedded fields (iframe)	The provider's fields sit inside your checkout, in iframes served by the provider	Stripe Elements, Adyen Drop-in and Components, Braintree Hosted Fields	High	SAQ A, if the 2025 script criterion is met
Your own form, sent to the gateway by script	Your page builds the form, a provider script sends the data straight to the gateway and returns a token	Authorize.net Accept.js with your own form	Full	SAQ A-EP
Direct API	Card numbers reach your server, which sends them to the gateway	Server-to-server card APIs	Full	SAQ D

Platform plugins for Shopify, WooCommerce and others are a fifth path, covered further down: they wrap one of the first two types.

Authorize.net puts the split in plain words. With Accept.js you "host your own payment form for a PCI-DSS SAQ A-EP solution", while its hosted form collects card data "in a PCI-DSS SAQ A compliant way".13 Adyen offers a Sessions flow, where your server makes one request and the client library handles the rest, and an Advanced flow with three requests for merchants who need checks before payment or a changing amount.12

Verdict

Start with a hosted page or the provider's embedded fields. Build your own form only when you can't get the checkout you need otherwise, and accept card numbers on your servers only with a reason worth hundreds of security controls.

Depth on the redirect option, its trade-offs and providers, is in our guide to hosted payment gateways.

PCI DSS scope: SAQ A, SAQ A-EP or SAQ D

PCI DSS applies to every merchant that accepts cards. What changes with the integration type is the self-assessment questionnaire (SAQ) you file each year, and the number of controls in it. Stripe sums up the stakes: a business that handles card data directly "might be required to meet more than 300 security controls in PCI DSS".5

The PCI Security Standards Council draws the line by the origin of each element of the payment page:

For SAQ A, all elements of the payment pages must only originate from PCI DSS compliant service provider(s). No single element of a payment page can originate from the merchant's website.

PCI Security Standards Council, FAQ on SAQ A and SAQ A-EP eligibility

For SAQ A-EP, each element of the payment page comes either from the merchant's website or from a compliant provider.3 That questionnaire covers e-commerce merchants whose website doesn't receive the card data but can affect the security of the payment page.4 If card numbers pass through your servers, neither applies.

What changed for SAQ A in 2025

On January 30, 2025, the PCI SSC published a new SAQ A. It removed requirements 6.4.3 and 11.6.1, the controls on payment page scripts, and requirement 12.3.1 that supported them. In exchange, it added an eligibility criterion: merchants must "confirm their site is not susceptible to attacks from scripts that could affect the merchant's e-commerce system(s)". The new version took effect on March 31, 2025, when the October 2024 version was retired.1

A month later, FAQ 1588 set the scope and the method.2

Who it applies to
E-commerce merchants whose webpage includes an embedded payment page or form from a provider, for example an iframe.
Who it doesn't
Merchants that redirect customers to the provider, or fully outsource payment, for example with a payment link sent by email.
How to confirm
Use techniques such as those in requirements 6.4.3 and 11.6.1, yourself or through a third party. Or get your provider's confirmation that its form, set up as instructed, protects your page from script attacks.

Practical rule

If you embed the gateway's fields, ask your provider in writing whether its solution covers the script criterion, and keep that answer with your SAQ. Your acquirer, not the gateway, confirms which questionnaire you file.

The full PCI picture, with what each questionnaire contains and how to pick a compliant gateway, is in our guide to PCI-compliant payment gateways.

How to integrate a payment gateway, step by step

The order below works for Stripe, Adyen, Braintree or Authorize.net. Names change, the steps don't.

Open the merchant account. The provider reviews your business, website, products and refund policy. Some businesses need more documents, and approval isn't automatic.
Get sandbox access and API keys. A publishable key for the browser, a secret key for your server only. Keep secrets out of the code.
Choose the integration type. Hosted page, embedded fields or your own form, based on the table above and the PCI questionnaire you can carry.
Build the client side. Load the provider's script from its own domain, collect the details in its fields, and receive a token or payment method ID. No card number reaches your code.
Build the server side. Create the payment from your server, with the amount from your database, never from the browser, and an idempotency key.
Handle webhooks. Verify the signature, store the event, answer fast, process it in a queue.
Handle 3D Secure. Let the provider's library run the authentication step, and treat "requires action" as a normal state.
Test. Approvals, declines, 3D Secure, duplicates, timeouts, refunds.
Go live. Swap to live keys, register live webhooks, watch the first payments.

Steps 1 and 2 can run in parallel: build in the sandbox while underwriting reviews your file.

Client side and server side: who does what

The rule fits in one line: the browser collects, the server decides. Anything the browser sends can be changed by the customer, including the amount.

Fig. 1Where the card data goes with embedded fields

approved declined or closed routing step

Customer's browserTypes the card in the provider's fields
card data goes straight toGatewayStores the card, returns a token
token onlyYour serverCreates the payment with the token and the real amount
secret keyGateway and issuerAuthorize, 3D Secure if neededApproved

your server only sees a token

Simplified flow. With a hosted page, steps 1 and 2 happen on the provider's page.

Tokens have limits worth knowing. At Authorize.net, the payment nonce returned by Accept.js is single-use and "valid for 15 minutes".13 Create the payment right after the customer submits, not in a later batch.

On the server, every request that creates or changes something gets an idempotency key. If the connection drops, you send the same request again with the same key, and the gateway returns the first result instead of charging twice. At Stripe, keys are up to 255 characters, Stripe suggests random V4 UUIDs, keys can be removed once they're at least 24 hours old, and a retry with different parameters returns an error.7

What you can keep is narrow. Stripe lists the card type, the last four digits and the expiry date as outside PCI scope, along with anything its API returns.5 The full card number and the security code stay with the gateway. More on that split in tokenization vs encryption.

Webhooks: the part that decides if orders are right

The response to your server call is only the first answer. Bank debits settle days later, 3D Secure finishes in the browser, refunds and disputes arrive weeks later, and renewals run with no customer present. Webhooks carry all of that.

Don't fulfill from the success page

Stripe is explicit: you can't rely on triggering fulfillment only from your checkout landing page, because "it's not guaranteed customers visit that page". A customer can pay and lose connection before it loads. Use the landing page to show the order, and the webhook to confirm it.8

Stripe and Adyen document the same rules, with different numbers:

Rule	Stripe	Adyen
Verify the sender	Check the `Stripe-Signature` header against the raw request body; reject old timestamps (5 minutes by default in the libraries)6	Verify the HMAC signature before using any data11
Acknowledge fast	Return a 2xx before any complex logic	Return 202 for most events; no answer within 10 seconds marks the webhook as failing11
Expect duplicates	The same event can arrive more than once: log processed event IDs	The same event can arrive twice, with the same `eventCode` and `pspReference`: use the latest
Don't expect order	Events aren't delivered in the order they were created	Check the timestamp, and the sequence number when present
Retries	Up to three days, with exponential backoff, in live mode6	Placed in a retry queue after the first attempts fail

The pattern that holds up: verify, store the raw event, answer 2xx, then process it from a queue. Stripe recommends the queue because renewal peaks, such as the start of the month, can overwhelm an endpoint that does everything inline.6 The fulfillment function itself must handle being called several times, even at the same moment, for the same payment.8

3D Secure and Strong Customer Authentication

In the EEA, the SCA rules make strong authentication the default for customer-initiated online card payments. An issuer can decline a payment that needed it and didn't get it, unless an exemption applies.15 The UK applies equivalent rules. Outside Europe, 3D Secure is optional but useful on risky orders.

In the integration, that means three things:

Let the provider's library run it. Hosted pages and embedded fields handle the challenge screen. With your own server flow, the payment comes back in a "requires action" state, and the browser must finish it.
Don't treat "requires action" as a failure. Keep the order pending until the webhook confirms the final result.
Flag saved cards correctly. The first payment authenticates the customer; later charges you start yourself go as merchant-initiated.

Exemptions, liability shift and subscriptions are covered in what payment authentication is.

Testing in the sandbox

Every gateway gives you test card numbers. Use them, never real cards: Stripe's terms forbid testing in live mode with real payment details, and Stripe warns that putting card numbers in server-side code, even in tests, can leave your code non-compliant when you go live.9

Approved card (Stripe: 4242 4242 4242 4242)The happy path, end to endOrder paid once, from the webhook
Generic decline (4000 0000 0000 0002) and insufficient funds (4000 0000 0000 9995)Your decline messages and order statesClear message, order stays unpaid, no fulfillment
3D Secure every time (4000 0027 6000 3184)The challenge flow and the pending stateOrder pending until authentication succeeds
Same request sent twiceIdempotency keysOne charge, the same response twice
Same webhook replayed, or events out of orderDuplicate and ordering handlingOne fulfillment, final state unchanged
Refund, then a test disputePost-payment eventsOrder, accounting and customer emails updated

Stripe's go-live checklist adds incomplete, invalid and duplicate data, and suggests having someone who isn't a developer test the checkout.10

Going live

Swap keysLive keys in, test keys out; rotate any key that left the codebase
Live webhooksRegister the live endpoint; check it handles delays, duplicates and any order
Recreate objectsProducts and plans from the sandbox don't exist in live mode
First live paymentsSmall real orders, refunded, then reconcile the payout

These points come from Stripe's go-live checklist, which also asks you to pin your API version, review error handling and check that your logs hold no card details or personal data you don't need.10 The same list applies to any gateway.

Platform plugins: Shopify, WooCommerce and headless

On a hosted store platform, most of the work above is done by the platform or the plugin.

Shopify
You activate or change a provider from the Payments page of the admin. Direct providers keep the customer on your store; external providers redirect to their own checkout. Shopify charges third-party transaction fees on payments through other gateways, even when Shopify Payments is activated.
WooCommerce
Each gateway is an extension: Stripe, PayPal and most others have one. Several can run at once and the customer picks at checkout. You keep the plugin updated, and the webhook settings it asks for.
Headless
Your front end calls the gateway's client library and your own server. You get the full step-by-step above, with no plugin to lean on.

The Shopify points come from Shopify's help center.14 A plugin doesn't remove PCI: your SAQ still depends on whether the plugin redirects or embeds, and whether your theme loads scripts on the payment page.

Multiple payment gateway integration

Merchants add a second gateway for four reasons: a backup when the first one is down, routing by country, currency or card type, payment methods the first gateway doesn't offer, and not depending on one provider's risk review. Each brings the same three problems.

Approach	How it works	Strength	Limit
Direct integration with each gateway	One integration per provider, your own routing code	Full control	You maintain every API, webhook format and status list
Platform with several methods	One provider that offers many payment methods, sometimes several acquirers	One integration	Routing and failover limited to what that provider offers
Store platform	Several gateways enabled side by side	NoCode	The customer picks, there's no automatic routing or failover
Orchestration layer	One integration to a layer that connects the processors	Routing, failover and one report	Another provider in the chain; check who holds the card vault

The three problems to solve

1. One routing decision. Something must decide which gateway takes each payment, and what happens when it fails. A technical failure can go to the next gateway. An issuer decline is different: card networks limit what you may retry and how often. The rules are in our guide to dynamic payment routing.

2. One vocabulary. Each gateway has its own statuses, decline codes and webhook formats. Map them to one internal list of payment states before anything reaches fulfillment, support or accounting.

3. Saved cards. This is the hard part. A token created at one processor can only be charged there. A subscription saved at Stripe can't renew at Adyen with the same token.

Fig. 2Who holds the card decides where it can be charged

A saved cardStored by one provider's vault

Stays in the processor's vaultOnly that processor can charge it
Forwarded by the vaultStripe Vault and Forward sends card details to supported endpoints, access through Stripe support
Exported on requestStripe can export card data to another PCI DSS compliant processor
Held by a neutral vaultAn orchestration layer stores the card and charges any connected processor

the vault is the real lock-in

Options documented by Stripe; other processors offer their own export or forwarding terms.

Stripe's Vault and Forward keeps cards in Stripe's vault and sends them to supported endpoints, including Adyen, Braintree, Checkout.com and Worldpay.16 Stripe also documents card data exports to another processor, on request.17 Plan this before the first subscription, not after. The layer around these choices is explained in what payment orchestration is.

Common payment gateway integration mistakes

Order marked paid from the success pageMissed orders when the customer closes the tab; fake confirmations if the URL is guessedFulfill from a verified webhook
Webhook handler that isn't idempotentDuplicate shipments, emails or subscription startsStore event IDs, make fulfillment safe to run twice
Amount taken from the browserCustomers can change the priceRead the amount from your database on the server
Card data in logs or your databaseYour PCI scope grows to every system that holds itKeep tokens and last four digits only, mask logs
No 3D Secure step for European customersIssuers decline payments that needed authenticationUse the provider's 3DS flow and handle the pending state
Extra scripts on the payment pageScript attack risk, and SAQ A at stake with an iframeInventory scripts, remove tags from checkout pages
Secret key in the front end or the repositoryAnyone can create refunds or read paymentsRotate the key, keep it server-side only

Stripe adds one more for any page that loads outside JavaScript: each third-party script makes your security depend on that site's, so keep them to a minimum on payment pages.5

Integrating several processors with Tagada

How Tagada helps

One checkout, TagadaPay, Stripe, NMI and Airwallex behind it

Tagada runs the checkout and connects the processors behind it, standalone or with Shopify, WooCommerce or a headless store. It routes payments across TagadaPay and processors such as Stripe, NMI and Airwallex, with one logic, and cascades to another processor when one is down or times out. Its card vault lets you switch processors without re-onboarding customers, so running subscriptions keep charging. 3D Secure 2 is native, with device intelligence and a rules engine. TagadaPay still underwrites each business. Details on the payments page and the pricing page.

Apply for processing

Whatever tool you pick, the checklist stays the same: an integration type you can defend at PCI time, server-side amounts, idempotent webhooks, 3D Secure where it's required, and a plan for saved cards before you add the second gateway.

Updated on October 14, 2026

Nick Bonnassies

CMO at Tagada

CMO at Tagada. Before Tagada, Nick built direct-to-consumer brands that generated over $115M in sales, raised over $25M in crowdfunding and sold two of them. He also works as a fractional CMO on marketing operations and AI systems.

Frequently asked questions

What is payment gateway integration?

It's the work of connecting your store or app to a payment gateway so customers can pay by card or other methods. It covers four parts: the form that collects payment details, the server call that creates the payment, the webhooks that confirm the result later, and reconciling those results with your orders and payouts.

Can I integrate multiple payment gateways on one website?

Yes. You can connect each gateway directly, use a platform that already offers several, or put an orchestration layer in front of them. Whatever the route, you need one place that decides which gateway handles each payment, one internal list of payment states, and a plan for saved cards, because a token created at one processor can't be charged at another.

Which PCI SAQ applies to my payment gateway integration?

It depends on who serves the payment form. If every element comes from a PCI DSS compliant provider, through a redirect or an iframe, you may qualify for SAQ A. If your own page builds the form and posts the data to the gateway, it's SAQ A-EP. If card numbers reach your servers, expect SAQ D. Your acquirer confirms which one you file.

Do I still qualify for SAQ A with an embedded iframe?

Since March 31, 2025, only if your payment page isn't susceptible to script attacks. The PCI SSC accepts two ways to confirm it: protections such as those in PCI DSS requirements 6.4.3 and 11.6.1, or a written confirmation from your gateway that its embedded form, set up as instructed, protects the page. Redirects aren't concerned.

What is the difference between payment gateway integration and implementation?

In practice, the two terms mean the same project. Integration usually refers to the technical connection: forms, API calls and webhooks. Implementation is the whole rollout: merchant account and underwriting, configuration, 3D Secure, testing in the sandbox, switching to live keys and monitoring the first live payments.

Do I need webhooks if my gateway returns a response right away?

Yes. The immediate response only covers the first step. Bank debits, 3D Secure, refunds, disputes and subscription renewals all change state later. Stripe states that you can't rely on the checkout landing page for fulfillment, because a customer can pay and lose connection before it loads. Webhooks are what tell your server the final result.
